47Y-20UNS4RA280 IN2005
| Thread Size | 3/4-1 | Application | | External Thread Milling | Internal Thread Milling | |
| Threads per Inch (TPI) | 20 | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | |
| Connection Diameter Machine Side (DCONMS) | 1/2″ | Cutting Edge Material | Carbide |
| Cutting Diameter (DC) | 0.472 | Usable Length (LU) | 1.08″ |
| Overall Length (OAL) | 3-1/2″ | Measurement Type | Inch |
| Flute Count (NOF) | 5 | Grade | IN2005 |
| Coating | TiAlN | Body Material | Carbide |
Product Features
| Country of Origin | Usa |
Shipping Info
Package Weight
0.273
